What air pressure is required for the pneumatic cylinder?

Standard double-acting cylinders operate at 4–7 bar (60–100 psi) filtered plant air. Supply FRL set point and line size on your RFQ for sizing confirmation.

Request enquiry · +91 97732 78770 · Indicative price list

Pneumatic Cylinder · DCS Ready · MSS SP-81

Pneumatic Knife Edge Gate Valve Manufacturer India

Double-Acting Cylinder · Solenoid · Limit Switches · FRL Package

Pneumatic actuated knife edge gate valves combine MSS SP-81 slurry-rated knife gates with robust double-acting pneumatic cylinders for fast, remote on-off control. Factory-assembled packages include 5/2 solenoid valve, open/close limit switches (proximity or mechanical), FRL air filter-regulator-lubricator, and ISO 5211 direct mount bracket. Ideal for ash handling, pulp mill DCS integration, mining tailings, and unmanned sewage plants.

Request Enquiry WhatsApp Download Catalog
EN 10204 3.1 MTC MSS SP-81 Tested Export & Domestic
Factory photoFactory photoFactory photo
Pneumatic Knife Edge Gate Valve Manufacturer India

Applications

Mining & Tailings

Isolation and line breaking on abrasive slurry, concentrate, and tailings pipelines.

Pulp & Paper

Black liquor, stock, and fibre slurry shut-off with minimal clogging.

Wastewater & Sewage

Raw sewage, grit, and biosolids handling in municipal and industrial plants.

Ash Handling & Power

Fly ash, bottom ash, and FGD slurry isolation in power and cement plants.

Cement & Bulk Solids

Powder, clinker, and pneumatic conveying line isolation.

Chemical Slurry

Viscous, solids-laden, and corrosive process media with SS316 or alloy options.

Complete Knife Edge Gate Valve Range

Uni-Directional

Flow in one direction — wafer/lug, slurry & pulp service

Bi-Directional

Shut-off from either direction — self-sealing option

Metal-to-Metal Seated

Stellite / SS seat for abrasive ash, dry solids & high temp

Soft Seated

EPDM, PTFE, Viton — bubble-tight Class VI closure

Pneumatic Cylinder

Double-acting cylinder, solenoid, limit switches, FRL

View Knife Edge Valves Hub

Technical Standards

Valve DesignMSS SP-81 knife edge gate
ActuatorDouble-acting pneumatic cylinder ISO 15552
Control5/2 solenoid valve 24V DC / 110V AC
FeedbackProximity or mechanical limit switches
Air Supply4–7 bar filtered plant air via FRL
MountingISO 5211 direct mount bracket

Special Features & Options

Material of Construction

Part No.Part NameMaterial / Standard
01Knife Gate ValveMSS SP-81 uni/bi-directional body
02Gate / SeatSoft or metal seated per service
03Pneumatic CylinderDouble-acting ISO 15552 / tie-rod
04Solenoid Valve5/2 way, 24V DC / 110V AC
05Limit SwitchesProximity or mechanical open/close
06FRL UnitFilter-Regulator-Lubricator assembly
07Mounting BracketISO 5211 direct mount
08Air Supply4–7 bar plant air (specify on RFQ)

Also available: Electric actuator (rotary/modulating), hydraulic cylinder for high-pressure mining, flameproof solenoid for hazardous areas.

Product SKU Page Download Datasheet

Request Knife Edge Gate Valve Quote

Send valve type (uni/bi-directional, seat type), size DN, end connection, actuation (manual/pneumatic), quantity, and application. Engineering response within 24 hours.

Or call +91 97732 78770 · info@supremevalves.in

Frequently Asked Questions

What air pressure is required for the pneumatic cylinder?

Standard double-acting cylinders operate at 4–7 bar (60–100 psi) filtered plant air. Supply FRL set point and line size on your RFQ for sizing confirmation.

Can you supply fail-close on air failure?

Yes. Single-acting spring-return cylinders fail-close (or fail-open per spec) on loss of air. Double-acting with stored air tank is also available.

Is the pneumatic package suitable for pulp mill DCS?

Yes. Packages include 24V DC solenoid and dry contact limit switches for PLC/DCS integration. Specify protocol (4–20 mA positioner) if modulating control is needed.

What valve sizes can be pneumatically actuated?

DN50 to DN600 standard with direct-mount cylinders. Larger sizes use scotch-yoke or rack-and-pinion actuators — quote on enquiry.
